OPA353NA

CMOS operational amplifier, 44MHz, 5.2mA, 2.5 V ~ 5.5 V, SOT23-5

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.10~100.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.10~100.00

PartNumber:: OPA353NA

Brand:: Texas Instruments - TI | Pack: SOT | D/C: 05+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Yolanda's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-01-31

From Other Seller

Part Number:OPA353NA
US $0.10 - 100.00
ECA1HHG4R7

US $10.00 - 10.00 / Piece
(0) Remove
AT25256AW-10SU-2.7

US $0.65 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The OPA353NA is a rail-to-rail CMOS operational amplifier. It is designed for low cost, miniature applications. The device is optimized for low voltage, single-supply operation. Rail-to-rail input/output, low noise (5nV/√Hz￣), and high speed operation (44MHz, 22V/μs) make it ideal for driving sampling analog-to-digital converters. The OPA353NA is also well suited for cell phone PA control loops and video processing (75Ω drive capability) as well as audio and general purpose applications. The applications of the OPA353NA include: cell phone pa control loops, driving a/d converters, video processing, data acquisition, process control, audio processing, communications, active filters, test equipment.

Parametrics

OPA353NA absolute maximum ratings: (1)Supply Voltage: 5.5V; (2)Signal Input Terminals, Voltage: (V–) – 0.3V to (V+) + 0.3V; Current: 10mA; (3)Output Short-Circuit: Continuous; (4)Operating Temperature:–55℃ to +125℃; (5)Storage Temperature: –55℃ to +125℃; (6)Junction Temperature: 150℃; (7)Lead Temperature (soldering, 10s): 300℃.

Features

OPA353NA features: (1)rail-to-rail input; (2)rail-to-rail output (within 10mv); (3)wide bandwidth: 44mhz; (4)high slew rate: 22v/μs; (5)low noise: 5nv/√hz; (6)low thd+noise: 0.0006%; (7)unity-gain stable; (8)microsize packages; (9)single, dual, and quad.
